| This cable harness provides efficient charging and high-speed data transmission services for mobile phones, tablets, computers, digital devices, small home appliances, and industrial control equipment. |
This cable harness provides efficient charging and high-speed data transmission services for mobile phones, tablets, computers, digital devices, small home appliances, and industrial control equipment. It is compatible with various scenarios such as device power supply, file transfer, and connection of external devices (such as USB flash drives and printers). It is a universal connection harness for daily office, home use, and industrial production! Supports mobile phones (Apple, Huawei, Xiaomi, and other brands), tablets, laptops, power banks, Bluetooth headsets, smartwatches, cameras, printers, automotive equipment, industrial sensors, and small home appliances (such as portable fans and humidifiers); Supports multiple interface combinations including USB-A male to Micro, USB-A male to Type-C, USB-C male to Type-C, and USB-A male to Lightning, with no reversible plugging (Type-C interface), ensuring smooth and seamless plugging and unplugging; Supports a wide voltage range of 5V-20V, compatible with PD20W/40W/65W fast charging protocols and USB 2.0/3.0/3.1 transmission protocols, backward compatible with normal charging/transmission modes, ensuring fast charging without damaging devices and instant data transfer.
| Item | Specification Details |
|---|---|
| Application Scenarios | USB interface devices such as smartphones, tablets, laptops, external hard disks, cameras, printers, set-top boxes, etc. |
| Core Purpose | High-speed data transmission, device charging, external device expansion (e.g., USB flash drives, keyboards, mice, monitors) |
| Compatible Protocols | USB 2.0, USB 3.2 Gen1 (5Gbps), USB 3.2 Gen2 (10Gbps), USB4 (40Gbps), USB PD 3.0 (fast charging protocol) |
| Electrical Parameters |
1. Charging: Rated Voltage 5V/9V/12V/15V/20V (PD protocol), Maximum Output Power 100W (20V/5A); 2. Data: Transmission Rate 480Mbps (USB2.0) / 5Gbps (Gen1) / 10Gbps (Gen2) / 40Gbps (USB4); 3. Insulation Resistance ≥1000MΩ, Withstand Voltage 500V AC/1min |
| Wire Specifications |
1. Conductor: Stranded tinned copper / silver-plated copper (conductivity ≥98%); 2. Power Core: AWG#22~#24 (0.3~0.5mm²), Data Core: AWG#28~#30 (0.08~0.14mm²); 3. Wire Structure: Power Core 16/0.16mm~24/0.16mm, Data Core 7/0.16mm (stranded, high flexibility) |
| Insulation/Sheath Material |
1. Insulation Layer: FEP/PVC (high temperature resistant, low loss); 2. Sheath: TPU / nylon braid (wear-resistant, anti-tangling); 3. Insulation Outer Diameter: Power Core φ1.0mm~φ1.5mm, Overall Wire Outer Diameter φ3.0mm~φ5.0mm |
| Interface Type |
1. Common Combinations: USB-A male → Type-C male, Type-C male → Type-C male, USB-A male → Micro-USB male; 2. Interface Material: Zinc alloy shell + gold-plated terminals (gold plating thickness 5~15μm); 3. Contact Resistance ≤5mΩ |
| Mechanical Properties | Wire Pull-out Force ≥20N; Bending Resistance ≥5 million times (bending radius ≥8mm); Plug-in Life ≥10,000 times; Interface Insertion/Extraction Force 8~20N |
| Environmental Adaptability | Operating Temperature -20℃~+85℃; Storage Temperature -40℃~+105℃; Salt Spray Test 48h no corrosion; Flame Retardant Grade UL 94V0 |
| Safety Certifications | USB-IF Certification, RoHS, CE, FCC, UL 94V0, GB/T 26572 |
| Included Accessories | Interface dust plugs, storage straps, cable organizers (for some high-end models), brand logo stickers |
If you are interested in any product, please contact us. We will introduce our products to you in more detail
