UL1365 Coaxial Electron Wire

Suitable for internal wiring in devices such as televisions and VCRs, it is a key cable for transmitting high-definition and high-frequency audio-visual signals.

Product Features:

It has the advantages of stable characteristic impedance and low signal attenuation, which can effectively isolate external interference and ensure the complete transmission of high-frequency signals.

Whats App Message Email

Product Description

UL1365 is a US standard coaxial cable certified to standards such as UL758 and UL1581. It features low-loss signal transmission and strong anti-interference capabilities, with a rated temperature of 60℃ and a rated voltage of 300V. Suitable for low-voltage applications sensitive to electromagnetic interference, such as audio-visual equipment and industrial control systems, it is a commonly used cable for signal and data transmission within electronic equipment.

Product Specifications

Wire Gauge (AWG)	Conductor Structure (Number of Strands / Wire Diameter mm)	Insulation Material & Thickness	Braided Shield Structure	Sheath Material & Thickness	Finished Outer Diameter (mm)
30	7/0.102	PE, 0.85mm	16/5/0.12	PVC, 0.75mm	4.00
28	7/0.127	PE, 1.10mm	16/5/0.12	PVC, 0.75mm	4.55
26	7/0.160	PE, 0.65mm	16/4/0.12	PVC, 0.55mm	3.40
26S	1/0.416	PE, 1.00mm	16/6/0.12	PVC, 0.75mm	4.40
24	7/0.203	PE, 1.70mm	16/8/0.12	PVC, 0.75mm	6.00
Additional Notes:	Besides the above, conductors can be single-strand or stranded bare copper/tinned copper. The insulation layer can also use flame-retardant PE, and the braided shield can be matched with copper materials to meet different customization needs.

Conductor: Outer insulation layer of PE, PEF, etc., with an outer braided layer of bare copper or tinned copper wire, and an outermost PVC or FEP sheath.

Rated Voltage: 300V
Rated Temperature: 60℃
